Tapered Roller Bearings 3017

Tapered Roller Bearings 3017 Featured Image
  • Tapered Roller Bearings 3017
  • Tapered Roller Bearings 3017
  • Tapered Roller Bearings 3017

Short Description:

Item No. 3017
Bearing Type Taper roller bearing (Metric)
Seals Type: Open,  2RS
Material Chrome steel GCr15
Precision P0,P2,P5,P6,P4
Clearance C0,C2,C3,C4,C5
Cage type Brass, steel, nylon, etc.
Ball Bearings Feature Long-life with high quality
Low-noise with strict controlling the quality of HJR bearing
High-load by the advanced high-technical design
Competitive price, which has the most valuable
OEM service offered, to meet the customers requirements
Application mill rolling mill rolls, crusher, vibrating screen, printing machinery, woodworking machinery, all kinds of industry
Bearing Package Pallet,wooden case,commercial packaging or as customers’ requirement


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month

    • Product Detail

    Product Tags

    圆锥1



    Cone Max Shaft Fillet Radii Cup Max Shaft Fillet Radii Bearing
    Number Bore Width Weight Number Outside Dia Width Weight Width
    d B R ① kg D C r① kg T
    322 29.972 22.174 0.8 0.3 312 72.626 23.812 3.3 0.19 26.988
    335 34.925 22.403 0.8 0.39 332 80 17.826 1.3 0.14 21
    339 35 22.403 0.8 0.39 333 80 21 2 0.16 21
    350A 40 21.692 0.8 0.4 352 90.119 21.808 2.3 0.32 23
    359A 46.038 21.692 3.5 0.33 352A 88.875 21.808 2.3 0.29 23
    365A 41.275 22.225 3.5 0.46 362 90 15.875 2 0.17 20
    368A 50.8 22.225 3.5 0.33 362A 88.9 16.513 1.3 0.16 20.637
    375 50.8 22.225 2.3 0.42 372 100 21.824 2 0.43 25
    385 55 21.946 2.3 0.44 382 98.425 17.826 0.8 0.22 21
    387A 57.15 21.946 3.5 0.4 382A 96.838 15.875 0.8 0.18 21
    390 57.15 21.996 2.3 394 110 22 0.8 0.28 22
    390A 63.5 21.996 1.5 394A 110 18.824 1.3 0.26 22
    395 63.5 21.996 3.5
    395A 66.675 21.996 0.8
    418 38.1 29.083 3.5 0.5 414 88.5 22.225 1.5 0.33 26.988
    435 44.45 29.9 0.8 0.56 432 95.25 22.225 2.3 0.38 27.783
    455 50.8 29.317 0.8 0.81 452 107.95 27 0.8 0.53 32.557
    459 40 29.317 2 0.98 453 107.95 27 0.8 0.48 27.795
    462 57.15 29.317 2.3 0.68
    469 57.15 29.317 3.5 0.68
    479 66.675 29.007 2.3 0.9 472 120 24.237 2 0.49 29.794
    482 69.85 29.007 3.5 0.82 472A 120 23.444 3.3 0.46 29.002
    495 82.55 29.769 3.5 1.07 492A 133.35 22.225 3.3 0.42 30.163
    495A 76.2 29.769 3.5 1.26 493 136.525 22.225 3.3 0.54 30.163
    497 85.725 29.769 3.5 0.98
    498 84.138 29.769 3.5 1.03
    527 44.45 36.068 3.5 0.95 J520 100 26.988 3.3 0.37 34.925
    528 47.625 36.068 3.5 0.89 522 101.6 26.988 3.3 0.41 34.925
    529 50.8 36.068 0.8 0.83 522A 100.038 31.75 4.3 0.44 39.688
    535 44.45 36.957 3.5 1.09 532 111.125 33.338 3.3 0.79 38.1
    537 50.8 36.957 3.5 0.96 532A 111.125 30.162 3.3 0.74 38.1
    539 53.975 36.957 3.5 0.88 533A 103.188 30.162 1.5 0.43 38.1
    555 50.8 36.678 2.3 1.56 552 123.825 33.338 3.3 0.8 38.1
    555S 57.15 36.678 3.5 1.4 552A 123.825 30.162 3.3 0.75 38.1
    559 63.5 36.678 3.5 1.23
    560 66.675 36.678 3.5 1.13
    567 73.025 36.17 3.5 1.15 562 130.048 28.575 0.8 0.8 36.512
    567A 71.438 36.17 3.5 1.2 563 127 28.575 3.3 0.64 36.512
    570 68.262 36.17 3.5 1.3
    575 76.2 36.098 3.5 1.6 572 139.992 28.575 3.3 0.77 36.513
    580 82.55 36.098 3.5 1.37 572A 139.982 28.575 3.3 0.74 35.25
    581 80.962 36.098 3.5 1.43 574 139.992 28.575 0.5 0.79 36.513
    593 88.9 36.322 3.5 1.7 592 152.4 33.338 3.3 1.1 39.688
    594 95.25 36.322 3.5 1.44
    596 85.725 36.322 3.5 1.83
    597 93.662 36.322 3.5 1.51
    598 92.075 36.322 3.5 1.58
    615 44.45 41.275 3.5 1.58 612 120.65 31.75 3.3 0.85 41.275
    637 60.325 41.275 3.5 1.89 632 136.525 31.75 3.3 1.04 41.275
    645 71.438 41.275 6.4 1.49 633 130.175 31.75 3.3 0.7 41.275
    663 82.55 41.275 3.5 1.88 652 152.4 31.75 3.3 1.24 41.275
    681 92.075 41.275 3.5 2.61 672 168.275 30.162 3.3 1.22 41.275
    683 95.25 41.275 3.5 2.46
    687 101.6 41.275 3.5 2.14
    740 80.962 46.672 5 2.34 742 150.089 36.512 3.3 1.07 44.45
    749 85.026 46.672 3.5 2.17
    749A 82.55 46.672 3.5 2.28
    755 76.2 48.26 3.5 3.09 752 161.925 38.1 3.3 1.59 47.625
    759 88.9 48.26 3.5 2.47 752A 159.995 38.1 0.8 1.47 47.625
    780 101.6 48.006 3.5 3.1 772 180.975 38.1 3.3 1.92 47.625
    782 104.775 48.006 3.5 2.91 772A 174.625 38.1 3.3 1.39 47.625
    795 120.65 47.625 3.3 4.46 792 206.375 34.925 3.3 1.88 47.625
    835 69.85 56.363 3.5 4.42 832 168.275 41.275 3.3 1.74 53.975
    861 101.6 57.531 8 4.15 852 190.5 47.625 3.3 2.78 57.15
    935A 109.1 74 spcl. 6.41 930 206.375 53.975 3.3 3.18 66.675
    938 114.3 86.675 7 5.77 932 212.725 53.975 3.3 4.07 66.675
    1280 22.225 22.225 0.8 0.18 1220 57.15 17.462 1.5 0.1 22.225
    1380 22.225 20.168 1.5 0.14 1328 52.388 14.288 1.5 0.07 19.367
    1380H 22.225 20.168 1.5 0.14 1330 50.8 15.875 1.5 0.06 20.002
    1680 33.338 20.638 3.5 0.19 1620 66.675 15.875 1.5 0.12 20.638
    1779 23.812 19.837 0.8 1730 53.975 15.875 0.8 0.07 19.638
    1986 25.4 19.355 1.3 0.17 1920 56.896 15.875 3.3 0.07 19.845
    1987 26.975 19.355 0.8 0.16 1930 56.896 15.875 0.8 0.07 19.845
    1988 28.575 19.355 3.5 0.14 1931 60.325 15.875 1.3 0.11 19.845
    A2047 11.986 10.785 0.8 0.03 A2126 31.991 7.938 1.3 0.02 10.008
    2380 22.225 24.765 0.8 0.21 2320 56.89 20.638 3.3 0.09 23.812
    2474 28.575 23.812 0.8 0.27 2420 68.262 17.462 1.5 0.14 22.225
    2559 30.162 25.357 0.8 0.3 2520 66.421 20.638 3.3 0.12 25.4
    2580 31.75 25.357 0.8 0.28 2525 72.022 19.05 0.8 0.2 23.813
    2688 26.988 25.433 1.5 0.26 2620 63.1 19.05 3.3 0.11 23.812
    2780 36.487 25.654 1.5 2720 76.2 19.05 3.3 0.18 23.775
    2788 38.1 25.654 3.5 2729 76.2 19.05 0.8 0.19 23.775
    2790 33.338 25.654 1.5 2735X 73.025 19.05 0.8 0.13 23.775
    3379 34.925 30.391 3.5 0.51 3320 80.157 23.812 3.3 0.21 29.37
    3384 41.275 30.391 0.8 0.43 3325 79.974 23.812 3.3 0.2 29.37
    3490 38.1 29.771 3.5 0.4 3420 79.375 23.812 3.3 0.25 29.37
    3578 44.45 30.886 3.5 0.47 3520 84.138 23.812 3.3 0.22 30.163
    3579 42.862 30.886 3.5 0.5 3525 87.312 23.812 3.3 0.3 30.163
    3660 20.638 30.416 2.3 0.32 3620 61.912 23.812 3.3 0.15 28.575
    3767 52.388 30.302 2.3 0.53 3720 93.264 23.812 3.3 0.28 30.163
    3779 47.625 30.302 3.5 0.62
    3780 50.8 30.302 3.5 0.56
    3782 44.45 30.302 3.5 0.67
    3872 34.925 30.162 3.5 0.64 3820 85.725 23.812 3.3 0.28 30.163
    3980 60.325 30.048 3.5 0.85 3920 112.712 23.812 3.3 0.44 30.163
    3982 63.5 30.048 3.5 0.78 3925 112.712 23.812 0.8 0.46 30.163
    3984 66.675 30.048 3.5 0.7 3926 112.712 26.988 3.3 0.53 33.338
    4338 41.275 40.386 3.5 0.8 4320 88.5 33.338 3.3 0.38 39.687
    4364 44.45 46.736 3.5 0.83 4335 90.488 33.338 3.3 0.45 39.687
    4559 45 40.157 3.5 1.19 4520 101.2 33.338 3.3 0.42 39.687
    JF4559 45 35 2.5 0.77 JF4510 95 30 2.5 0.42 36
    JW4559 45 26.5 2.5 0.57 JW4510 95 20 2.5 0.34 29
    A5069 17.455 11.112 1.5 0.03 A5144V 36.525 7.938 1.5 0.02 11.112
    A5669V 17.455 11.112 1.5 0.03 A5144 36.525 7.938 1.5 0.02 11.112
    JW5049 50 29 3 0.77 JW5010 105 22 3 0.46 32
    5356 44.45 44.475 1.3 1.24 5320 101.2 36.512 3.3 0.54 43.657
    5565 50.8 43.764 1.3 1.89 5520 120.251 36.512 3.3 0.71 44.45
    JS5547 52.4 29.5 4 0.7 JS5510 100 24 2.5 0.36 30
    JW5549 55 31 3 1 JW5510 115 23.5 3 0.57 34
    JF6049 60 39 2.5 1.24 JF6010 115 33 2.5 0.62 40
    6379 65.088 56.007 3.5 2.24 6320 135.755 44.45 3.3 1.37 53.975
    6386 66.675 56.007 4.3 2.17
    6461 76.2 54.29 3.5 6420 149.225 44.45 3.3 1.62 53.975
    6580 88.9 55.1 3.5 3.02 6525X 160 44.45 3 1.52 53.975
    6581X 90 55.1 3 2.95 6535 161.925 42.862 3.3 1.65 53.974
    JF7049 70 42 3 1.7 JF7010 130 35 2.5 0.8 43
    JW7549 75 38 3 2.05 JW7510 150 29 3 1.17 42
    9180 61.912 46.038 3.5 2.88 9120 158.75 34.925 3.3 1.82 50.8
    9278 68.262 46.038 3.5 3.27 9220 161.925 31.75 3.3 1.37 49.212
    9380 76.2 46.038 3.5 3.62 9320 177.8 34.925 3.3 2.19 52.387
    2474 28.575 22.225 0.8 0.25 2420 68.262 17.462 1.5 0.15 22.225
    2475 31.75 22.225 3.5 0.22
    2872 28.575 22.225 0.8 0.33 2820 73.025 17.462 3.3 0.15 22.225
    5079 19.987 14.381 1.5 5175 44.45 11.43 1.5 0.03 15.494
    7093 23.812 14.26 1.5 0.09 7196 50.005 9.525 1 0.03 13.495
    8125 31.75 15.08 1 0.11 8231 58.738 10.716 1 0.06 14.683
    9067 19.05 19.05 1.3 0.11 9095 49.225 14.288 1.3 0.06 18.034
    JP10049 100 22.5 3 0.82 JP10010A 140 17.5 0.8 0.33 24
    11162 41.275 17.384 1.5 0.21 11300 76.2 14.288 1.5 0.13 18.009
    11590 15.875 14.288 1.5 0.06 11520 42.862 9.525 1.5 0.04 14.287
    LM11749 17.462 14.605 1.3 0.06 LM11710 39.878 10.668 1.3 0.03 13.843
    JP12049 120 25 3 1.25 JP12010 170 19.5 3 0.48 27
    12580 20.638 19.845 1.5 0.12 12520 49.225 15.875 1.5 0.07 19.845
    M12648 22.225 18.288 1.3 0.11 M12610 50.005 13.97 1.3 0.06 17.526
    M12649 21.43 18.288 1.3 0.11
    LM12748 21.43 16.637 1.3 0.08 LM12710 45.237 12.065 1.3 0.04 15.494
    LM12749 21.986 16.637 1.3 0.08 LM12711 45.974 12.065 1.3 0.04 15.494
    JP13049 130 27 3 1.58 JP13010 185 21 3 0.59 29
    13686 38.1 26.195 1.5 0.25 13620 69.012 15.083 0.8 0.1 19.05
    13890 38.481 11.908 0.4 13830 63.5 9.525 0.8 0.04 12.7
    14116 30.226 19.583 0.8 0.23 14272 69.012 14.288 3.3 0.11 19.05
    14118 30 19.202 0.8 0.23 14273 69.012 16.954 spcl. 0.11 19.337
    14125A 31.75 19.583 3.5 0.22 14276 69.012 15.875 1.3 0.13 19.845
    14131 33.338 19.583 0.8 0.21
    14138A 34.925 19.583 3.5 0.19
    JP14049 140 27 3 1.68 JP14010 195 21 3 0.62 29
    14585 34.925 20.638 3.5 0.2 14525 68.262 15.875 2.3 0.12 20.638
    15101 25.4 20.638 0.8 0.22 15243 61.912 14.288 2 0.08 19.05
    15106 26.988 20.638 0.8 0.2 15245 62 14.288 1.3 0.08 19.05
    15123 31.75 19.05 spcl. 0.15
    15578 25.4 17.462 1.3 0.15 15520 57.15 13.495 1.5 0.07 17.462
    15580 26.988 17.462 3.5 0.13
    15590 28.575 17.462 3.5 0.12
    15575X 23.812 18.161 0.8 0.16
    16150 38.1 20.638 3.5 0.21 16282 72 14.237 1.5 0.12 19
    16284 72.238 15.875 1.3 0.14 20.638
    JP16049 160 30 3 2.32 JP16010 220 23 3 0.85 32
    JP17049 170 30 3 2.51 JP17010 230 23 3 0.92 32
    17888 44.45 31.354 3.8 0.38 17830 79.375 15.875 2 0.13 31.354
    17887 45.23 20.638 2 0.27 17831 79.985 15.08 1.3 0.13 30.559
    JP18049 180 30 3 2.61 JP18010 240 23 3 0.97 32
    18590 41.275 17.462 3.5 0.19 18520 73.025 12.7 1.5 0.08 16.667
    18690 46.038 17.462 2.8 0.21 18620 79.375 13.495 1.5 0.12 17.462
    18790 50.8 17.462 3.5 0.23 18720 85 13.495 1.5 0.13 17.462
    21075 19.05 21.839 1.5 0.15 21212 53.975 15.875 2.3 0.09 22.225
    L21549 15.875 10.998 1.3 0.03 L21511 34.989 8.712 1.3 0.02 10.998
    22780 42.862 26.988 3.5 0.4 22720 82.55 20.638 3.3 0.22 26.195
    23100 25.4 21.463 1.5 0.22 23250 23.5 14.681 2.3 0.11 21.691
    24118 30.162 18.974 1.5 0.18 24261 66.421 15.875 1.5 0.12 19.052
    24780 41.275 23.02 3.5 0.28 24720 76.2 17.462 0.8 0.15 22.225
    25577 42.875 25.4 3.5 0.37 25518 81.973 19.114 1 0.18 23.876
    25578 42.862 25.4 2.3 0.38 25519 82.55 19.05 2 0.19 23.813
    25580 44.45 25.4 3.5 0.35 25520 82.931 19.05 0.8 0.2 23.813
    25584 44.983 25.4 1.5 0.35
    25590 45.618 25.4 3.5 0.33
    25877 34.925 24.608 1.5 25821 73.025 19.05 0.8 0.17 23.813
    26118 29.987 18.923 1.5 0.22 26283 72 15.875 1.5 0.16 19
    JL26749F 32 15 spcl. 0.08 JL26710 53 11.5 1.3 0.04 14.5
    26878 38.1 25.4 0.8 0.39 26820 80.167 20.638 3.3 0.21 25.4
    27687 82.55 25.4 3.5 0.7 27620 125.412 19.845 1.5 0.34 25.4
    26790 83.345 25.4 3.5 0.68
    27880 38.1 23.698 0.8 0.36 27820 80.035 18.512 1.5 0.21 24.608
    28580 50.8 25.4 3.5 0.46 28520 89.98 19.987 2.3 0.2 24.75
    28584 52.388 25.4 3.5 0.43 28521 92.075 19.845 0.8 0.24 24.607
    28680 55.562 24.608 3.5 0.49 28622 97.63 19.446 0.8 0.27 24.608
    28682 57.15 24.608 3.5 0.46
    28985 60.325 25.4 3.5 0.53 28920 101.6 19.845 3.3 0.26 25.4
    29585 63.5 25.4 3.5 0.65 29520 107.95 19.05 3.3 0.27 25.4
    29590 66.675 25.4 3.5 0.58 29522 107.95 19.05 0.8 0.28 25.4
    29675 69.85 25.4 1.5 0.69 29620 112.712 19.05 3.3 0.27 25.4
    29685 73.025 25.4 3.5 0.62
    LM29748 38.1 18.288 spcl. 0.14 LM29710 65.088 13.97 1.3 0.08 18.034
    LM29749 38.1 18.288 2.3 0.15 LM29711 65.088 15.748 1.3 0.09 19.812
    31590 33.338 28.575 0.8 0.41 31520 76.2 23.812 3.3 0.23 29.37
    31594 34.925 28.575 1.5 0.4
    33262 66.675 30.162 3.5 0.9 33462 117.475 23.812 3.3 0.43 30.162
    33275 69.85 30.162 3.5 0.82 33472 120 23.444 0.8 0.52 29.794
    33281 71.438 30.162 3.5 0.78
    33287 73.025 30.162 3.5 0.74
    33690 146.05 28.575 1.5 1.55 36620 193.675 23.02 1.5 0.72 28.575
    36990 177.8 30.162 1.5 2 36920 227.012 23.02 1.5 0.9 30.163
    37425 107.95 21.438 3.5 0.88 37625 158.75 158.75 3.3 0.47 23.02
    37431 109.538 21.438 3.5 0.84
    39581 57.15 30.162 8 0.99 39520 112.712 23.812 3.3 0.36 30.163
    39585 63.5 30.162 3.5 0.88
    39590 66.675 30.162 3.5 0.81
    41125 28.575 24.257 4.8 0.28 41286 72.626 17.462 1.5 0.18 24.607
    42375 95.25 28.971 3 1.19 42587 149.225 24.608 3.3 0.69 31.75
    42381 96.838 28.971 3.5 1.12
    42687A 76.2 31 1.3 1.01 42620 127 22.225 3.3 0.43 30.163
    L44643 25.4 14.732 1.3 0.09 L44610 50.292 10.668 1.3 0.04 14.224
    L44649 26.988 14.732 3.5 0.08
    45280 44.45 30.958 0.8 1 45220 104.775 23.812 3.3 0.35 30.162
    45284 50.8 30.958 6.4 0.86 45221 104.775 23.812 0.8 0.35 30.162
    45290 57.15 30.958 2.3 0.75
    L45449 29 14.732 3.5 0.08 L45410 50.292 10.668 1.3 0.03 14.224
    46143 36.512 31.75 1.5 0.75 46368 93.662 26.195 3.3 0.4 31.75
    47490 71.438 32.545 3.5 0.94 47420 120 26.195 3.3 0.47 32.545
    47675 71.438 33.338 3.5 1.48 47620 133.35 26.195 3.3 0.56 33.337
    47679 76.2 33.338 3.5 1.34 47621 139.992 29.37 3.3 0.99 36.512
    47686 82.55 33.338 3.5 1.13
    47890 92.075 34.925 3.5 1.41 47820 146.05 26.195 3.3 0.65 33.337
    48290 127 38.1 3.5 2.18 48220 182.562 33.338 3.3 1.12 39.689
    48393 136.525 39.688 3.5 2.21 48320 190.5 33.338 3.3 1.14 39.687
    LM48545 35.128 18.288 0.8 0.17 LM48510 65.088 13.97 1.3 0.09 18.034
    LM48548 34.925 18.288 spcl. 0.16
    LM48549 34.925 18.288 1.5 0.17
    48685 142.875 39.688 3.5 2.47 48620 200.025 34.13 3.3 1.37 41.275
    49175 44.45 31.75 3.5 0.64 49368 93.662 25.4 3.3 0.36 31.75
    49581 47.625 31.75 6.4 0.78 49520 101.6 25.4 3.3 0.38 31.75
    52375 95.25 36.116 3.5 1.99 52618 157.162 26.195 3.3 0.69 36.512
    LL52549 22.225 11.176 1.3 0.04 LL52510 42.07 8.636 1.3 0.02 11.176
    53176 44.45 28.3 1.3 0.59 53387 98.425 20.638 0.8 0.44 30.956
    55176 44.45 26.909 0.8 0.87 55437 111.125 20.638 3.3 0.5 30.163
    55206 52.388 26.909 3.5 0.74
    55187C 47.625 26.909 3.5 0.91 55437 111.125 20.638 3.3 0.5 30.163
    56418 106.362 36.512 3.5 1.86 56650 165.1 26.988 3.3 0.84 36.512
    56425 107.95 36.512 3.5 1.78
    59175 44.45 36.512 3.5 1.08 59425 107.95 28.575 3.3 0.58 36.512
    64450 114.3 41.275 3.5 2.36 64700 177.8 30.162 3.3 1.09 41.275
    65237 60.325 44.45 3.5 1.57 65500 127 34.925 3.3 1.02 44.45
    65385 44.45 44.45 3.5 1.44 65320 114.3 34.925 3.3 0.87 44.45
    65390 49.212 44.45 3.5 1.32 65321 114.3 34.925 0.8 0.88 44.45
    66212 53.975 31.75 3.5 1.04 66462 117.45 23.812 3.3 0.54 33.338
    66584 53.975 31.75 3.5 1.24 66520 122.238 23.812 3.3 0.54 33.338
    67425 107.95 30.162 3.5 1.63 67675 171.45 25.2683.3 0.9 34
    LM67048 31.75 16.764 spcl. 0.12 LM67010 59.131 11.811 1.3 0.06 15.875
    67388 127 46.038 3.5 3.65 67320 203.2 38.1 3.3 2.04 46.038
    67780 165.1 47.625 3.5 5.62 67720 247.65 38.1 3.3 2.29 47.625
    67790 177.8 47.625 3.5 4.35
    67983 203.2 46.038 3.5 5.96 67920 282.575 36.512 3.3 2.79 87.312
    JL68145 35 18.461 2 0.12 L68110 59.131 11.938 1.3 0.06 15.875
    L68149 34.988 16.764 spcl. 0.11 JL68111Z 60 11.938 1.3 0.06 15.875
    L68149A 34.988 16.764 0.8 0.12 L68111 59.974 11.983 1.3 0.06 15.875
    JL69349 38 17 spcl. 0.13 JL69310 63 13.5 1.5 0.07 17
    71425 107.95 49.212 3.5 3.85 71750 190.5 34.925 3.3 1.72 47.625
    72212 53.975 32.791 3.5 1.16 72487 123.825 25.4 3.3 0.78 36.512
    72225 57.15 32.791 3.5 1.09 72500 127 25.4 3.3 0.9 36.512
    LM72849 22.606 15.5 1.5 0.08 LM72810 47 12 1 0.05 15.5
    73551 139.7 31.623 3.5 2.83 73875 222.5 23.812 3.3 1.43 60.579
    74550 139.7 47.625 3.5 4.06 74845 214.975 34.925 3.3 1.84 47.625
    77376 95.25 48.26 6.4 2.97 77675 171.45 38.1 3.3 1.65 47.625
    78215 53.975 33.236 3.5 1.73 78537 136.525 23.52 3.3 0.76 36.513
    LM78349 34.988 17 3.5 0.12 LM78310A 61.973 13.6 1.5 0.07 16.702
    M84249 25.4 23.114 0.8 0.2 M84210 59.53 18.288 1.5 0.13 23.368
    M84548 25.4 19.431 1.5 0.15 M84510 57.15 14.732 1.5 0.09 19.431
    M86643 25.4 21.433 1.5 0.24 M86610 64.292 16.67 1.5 0.13 21.432
    M86647 28.575 21.433 1.5 0.22
    M86649 30.162 21.433 1.5 0.21
    M88043 30.162 22.225 2.3 0.26 M88010 68.262 17.462 1.5 0.14 22.225
    HM88542 31.75 27.783 1.3 0.38 HM88510 73.025 23.02 3.3 0.23 29.37
    HM88547 33.338 27.783 0.8 0.36 HM88511 73.025 23.02 0.8 0.24 29.37
    HM88649 34.925 25.4 2.3 HM88610 72.233 19.842 2.3 0.18 25.4
    HM89249 36.512 28.829 3.5 0.44 HM89210 79.375 22.664 3.3 0.26 29.37
    HM89440 31.75 28.575 0.8 0.44 HM89410 76.2 23.02 3.3 0.25 29.369
    HM89443 33.338 28.575 0.8 0.42
    HM89446 34.925 28.575 3.5 0.4
    HM89449 36.512 28.575 3.5 0.38
    90381 96.838 46.038 3.5 3.82 90744 188.912 31.75 3.3 1.87 50.8
    93800 203.2 63.5 4.3 11.89 93125 317.5 46.038 3.3 5.98 63.5
    94700 177.8 63.5 7 9.96 94113 288.925 47.625 3.3 5.32 63.5
    95500 127 63.5 6.4 7.68 95925 234.95 49.212 3.3 4.04 63.5
    98400 101.6 49.212 3.5 4.54 98788 200 34.925 3.3 2.28 52.761
    99600 152.4 66.675 7 8.23 99100 254 47.625 3.3 4.24 66.675
    L102849 44.45 18.258 1.5 0.2 L102810 73.025 15.083 1.5 0.1 18.258
    LM102949 45.242 19.812 3.5 0.21 LM102910 73.431 15.748 0.8 0.1 19.558
    LL103049 44.45 12.7 1.5 0.13 LL103010 71.438 9.525 1.5 0.05 12.7
    JLM104948 50 21.5 3 JLM104910 82 17 0.5 0.13 21.5
    LM104949 50.8 22.225 3.5 LM104911 82.55 16.51 1.3 0.13 21.116
    LM110848 63.5 25.4 1.5 0.49 LM110811 101.6 22.225 1.5 0.27 25.4
    L117549 88.9 19.05 2.3 0.53 L117510 125.412 15.083 2.3 0.18 19.05
    LM117949 88.9 28.575 2.3 0.88 LM117910 130.175 25.4 2.3 0.44 28.574
    LM120749 101.6 31.75 2.3 1.13 LM120710 146.05 28.575 2.3 0.62 31.75
    LM122948 114.3 34.925 3.3 1.31 LM122911 158.75 30.162 3.3 0.68 34.925
    LM124449 120.65 36.512 3.3 1.5 LM124410 166.688 31.75 3.3 0.76 52.387
    HM124649 119.957 57.15 3 3.58 HM124618 195.262 44.45 3.3 2.45 53.975
    EE132083 203.2 53.975 4 9.81 132127 319.088 34.925 3.3 4.35 95.25
    EE132084 206.375 53.975 4 9.38 132125 317.5 34.925 3.3 4.13 53.975
    HM134940 165.087 74.612 1.5 22.88 HM136916D 276.225 185.725 17.12 181.022
    EE157337 857.25 111.125 19 157430 1092.2 76.2 6.4 70.52 120.65
    EE158350 889 111.125 19 158442 1123.95 76.2 6.4 73.14 120.65
    EE195500X 127 67.335 4.8 16.62 195116X 295.275 50.8 4.8 10.23 82.55
    EE197045 114.3 74.612 3.3 11.7 197100 254 49.212 6.4 6.49 77.787
    M201047 39.688 22.098 0.8 0.26 M201011 73.025 21.336 2.3 0.17 25.654
    HM204043 39.978 32 1 0.73 HM204010 90.975 26.5 3.5 0.3 32
    JM205149 50 28 3 0.51 JM205110 90 23 2.5 0.24 28
    JM207049 55 29 1.5 0.59 JM207010 95 23.5 2.5 0.25 29
    HM212047 63.5 38.354 7 1.36 HM212010 122.238 29.718 1.5 0.6 38.1
    HM212049 66.675 38.354 3.5 1.27 HM212011 122.238 29.718 3.3 0.6 38.1
    H212749 65.987 41.5 7 1.46 H212710 123.975 34 3.5 0.67 41.5
    EE213362 92.075 73.025 9.7 7.88 213843 214.312 58.975 6.4 4.45 73.025
    EE215040 101.6 73.025 6.4 10.44 215096 250.825 50.8 3.3 6.9 76.2
    HM215249 75.987 39 7 1.46 HM215210 131.976 32 3.5 0.65 39
    JH217249 85 46 3 2.28 JH217210 150 38 2.5 1.08 46
    L217849 88.9 20.638 1.5 0.51 L217810 123.825 16.67 1.5 0.24 20.637
    LL217849 88.9 15.083 1.5 0.35 LL217810 121.442 11.112 1.5 0.13 15.082
    HM218248 89.974 40 7 1.77 HM218210 146.975 32.5 3.5 0.79 40
    EE219065 165.1 82.55 6.4 17.25 219117 298.45 63.5 6.4 6.98 82.55
    EE219068 174.25 82.55 6.4 15.6 219122 311.15 63.5 6.4 9.99 82.55
    HM220149 99.974 42 8 1.96 HM220110 156.975 34 3.5 0.86 42
    EH220749 95.25 73.025 3.3 7.19 EH220710 200.025 58.738 3.3 3.45 73.025
    HH221449 101.6 57.531 8 4.99 HH221410 190.5 46.038 3.3 2.21 57.15
    HH224332 98.425 66.675 3.5 8.85 HH224310 212.725 53.975 3.3 3.03 66.674
    HH224349 114.976 66.675 7 7.34
    M224749 120.65 36.512 3.5 1.83 M224710 174.625 27.783 1.5 0.86 35.72
    H225148 117.475 69.85 8 6.34 H225110 212.725 49.212 3.3 3.06 63.5
    LL225749 127 17.462 1.5 0.64 LL225710 165.895 13.495 1.5 0.28 18.257
    L225849 127 26.195 1.5 1.09 L225810 169.862 20.638 1.5 0.52 25.4
    HH228349 127 82.55 9.7 12.63 HH228310 254 61.912 6.4 5.98 77.788
    M229349 146.05 40 3.5 2.64 M229310 203.2 38.1 3.5 1.37 45.1
    H230844 139.7 68.262 14.3 8.14 H230811 241.3 50.8 3.3 3.7 63.5
    H230847 144.462 68.262 3.3 7.63 H230818 247.65 50.8 3.3 4.61 63.5
    HM231148 149.225 56.642 6.4 6.35 HM231110 236.538 44.45 3.3 2.8 57.15
    HM231149 149.225 56.642 3.5 6.41
    M231649 152.4 46.83 3.5 3.93 M231610 222.25 34.925 1.5 1.86 46.83
    HH234048 152.4 93.662 9.7 20.51 HH234010 307.975 66.675 6.8 8.62 88.9
    HM234648 165.1 71.438 1.5 9.67 HM234610 266.7 50.8 3.3 4.17 66.675
    M235149 170 46.038 4.8 5.2 M235110DA 250.825 76.2 0.8 4.78 101.6
    LM236749 184.15 33 2 2.39 LM236710 234.95 28 2 0.98 34
    M236849 177.8 53.975 3.5 6.23 M236810 260.35 41.275 3.3 2.82 98.425
    HM237540 171.45 63.5 7 11.92 HM237510 288.925 47.625 3.3 4.46 63.5
    LM241147 200.025 46.038 3.5 5.65 LM241110 276.225 34.133 3.3 2.1 42.863
    LM241148 203.987 46.038 3.5 5.2 LM241111 276.225 34.133 3.3 2.15 42.863
    M241549 204.788 57.945 3.5 7.95 M241510 292.1 46.038 3.3 3.86 57.945
    H242649 206.375 100.012 3.3 22.33 H242610 336.55 77.788 3.3 10.95 98.425
    LL244549 231.775 21.5 2 1.28 LL244510 268.288 18.5 2 0.57 22.5
    LM300849 40.988 18 spcl. 0.16 LM300811 67.975 13.5 1.5 0.08 17.5
    L305649 50.8 18.258 1.5 0.24 L305610 80.962 14.288 1.5 0.12 18.257
    JH307749 55 39 3 1.14 JH307710 110 32 2.5 0.57 39
    L319249 95.25 21.433 1.5 0.55 L319210 130.175 16.67 1.5 0.24 20.638
    LL319349 95.25 15.038 1.5 0.38 LL319310 128.587 11.908 1.5 0.15 15.875
    HM321245 99.212 49.212 3.5 3.18 HM321210 171.45 38.1 3.3 1.38 49.213
    L327249 133.35 26.195 1.5 1.17 L327210 177.008 20.638 1.5 0.54 25.4
    M327345 127 46.038 3.5 3.58 67322 196.85 38.1 3.3 1.44 46.036
    M327349 133.35 46.038 3.5 3.11
    LM328048 139.7 39.688 3.3 2.01 LM328011 188.912 33.338 3.3 1.07 39.688
    LM328444 136.525 29.37 1.5 1.72 LM328410 187.325 23.02 1.5 0.69 28.575
    LM330446 150.812 41.275 3.3 2.4 LM330410 203.2 34.925 3.3 1.2 41.275
    M336946 177.8 57.15 3.3 6.76 M336912 265.112 38.895 3.3 2.73 51.595
    H414245 68.262 41.275 3.5 1.97 H414210 136.525 31.75 3.3 0.78 41.275
    H414249 71.438 41.275 3.5 1.86
    JH415647 75 51 3 2.62 JH415610 140 42 2.5 1.19 51
    L420449 101.6 21.433 1.5 0.58 L420410 136.525 16.67 1.5 0.27 21.433
    LL420549 101.6 15.083 1.5 0.4 LL420510 134.938 11.908 1.5 0.16 15.875
    LL428349 139.7 20.638 1.5 0.89 LL428310 180.975 16.67 1.5 0.42 21.432
    JH429149 130 72 8 9.55 JH429110 240 60 7 4.82 76
    L432348 158.75 23.812 4.8 1.29 L432310 205.582 18.258 1.5 0.58 23.812
    L432349 158.75 23.812 1.5 1.34
    H432649 152.387 77.778 1.5 11.72 H432610 269.875 64 3.3 6.5 77
    LM446349 234.95 46.038 3.5 6.22 LM446310 311.15 33.338 3.3 2.55 46.037
    J450590 150 80 5 17.17 451250 317.5 61.912 6.8 12.82 88.9
    LM451349 266.7 57.15 3.5 10.52 LM451310 355.6 44.45 3.3 4.36 107.95
    LM501349 41.275 19.812 3.5 0.23 LM501310 73.431 14.732 0.8 0.11 38.895
    LM501314 73.431 16.604 0.8 0.13 42.639
    LM501311 73.431 18.186 2.3 0.14 23.012
    LM503349 45.987 18 2.3 0.21 LM503310 74.976 14 1.5 0.09 18
    JLM506849 55 23 1.5 0.36 JLM506810 90 18.5 0.5 0.18 23
    L507949 57.15 18.258 1.5 0.26 L507910 87.312 14.288 1.5 0.13 18.258
    JM511946 65 28 3 0.72 JM511910 110 22.5 2.5 0.33 28
    JM515649 80 34 3 1.14 JM511610 130 28.5 2.5 0.57 35
    HM515749 79.375 46.1 3.5 1.66 HM515714 140 33.338 3.3 0.94 44.45
    HM516449A 82.55 39.688 6.2 1.35 HM516410A 133.35 32.545 0.8 0.77 39.687
    JHM516849 85 38 3 1.51 JHM516810 140 31.5 2.5 0.76 39
    HM518445 88.9 39.688 6.4 2.05 HM518410 152.4 30.162 3.3 0.76 39.688
    LM520349 101.6 21.717 1.5 1.57 LM520310D 146.05 38.895 0.8 0.78 49.209
    LL521845 104.775 15.083 1.6 0.5 LL521810 142.083 11.908 1.5 0.18 15.875
    LL521849C 107.95 15.083 1.6 0.44 LL521811 142.083 11.908 1.5 0.18 15.875
    L521949 107.95 21.433 1.5 0.66 L521910 146.05 16.67 1.5 0.33 21.432
    LM522549 109.987 34.925 3.5 1.52 LM522510 159.987 26.988 3.3 0.75 69.058
    JHM522649 110 46 3 3.05 JHM522610 180 38 2.5 1.49 47
    LL529749 146.05 20.638 1.5 0.94 LL529710 188.12 16.67 1.5 0.45 22.225
    M533349S 165.1 44 3.5 3.83 M533310 231.976 36 3.5 1.7 45
    JHM534149 170 38 3 3.04 JHM534110 230 31 2.5 1.28 39
    HM535347 169.974 66.675 3.5 8.49 HM535310 260.35 52.388 3.3 4.18 66.675
    HM535349 171.45 66.675 3.5 8.23
    LL537649 184.15 25.4 1.5 1.82 LL537610 236.538 19.05 1.5 0.79 26.193
    L540049 196.85 27.783 1.5 2.34 L540010 254 21.433 1.5 1.02 28.575
    544090 228.6 31.75 3.5 3.71 544118 300.038 23.812 3.3 1.87
    LM603049 45.242 19.842 3.5 0.25 LM603011 77.788 15.08 0.8 0.12 39.687
    LM603012 77.788 16.667 0.8 0.14 42.862
    LM603014 79.974 15.08 0.8 0.15 39.687
    L624549 120.65 21.433 1.5 0.77 L624510 160.338 16.67 1.5 0.39 21.433
    L624511 158.75 16.67 1.5 0.34 21.433
    L630349 152.4 24 2 1.1 L630310 192.088 19 2 0.46 25
    LL641148 203.479 31.75 1.5 2.68 LL641110 261.142 21.433 1.5 1.05 28.575
    LL641149 203.2 27.783 1.5 2.47 LL641111 261.142 21.433 1.5 1.07 28.575
    JLM704649 50 22 3.5 0.3 JLM704610 84 17.5 1.5 0.16 22
    L713049 69.85 19.05 1.5 0.34 L713010 101.6 15.083 1.5 0.17 19.05
    JLM714149 75 25 3 0.61 JLM714110 115 19 2.5 0.27 25
    JM714249 75 29.5 3 0.88 JM714210 120 25 2.5 0.42 31
    H715341 66.675 46.038 3.5 2.34 H715310 139.7 36.512 3.3 1.14 46.038
    LM716449 82.55 26.988 3.5 0.82 LM716411 129.974 20.638 1.5 0.41 26.987
    JM716649 85 29 3 0.9 JM716610 130 24 2.5 0.45 30
    JM718149 90 34 3 1.49 JM718110 140 27 2.5 0.65 35
    LM718947 91.973 30 3.5 1.15 LM718910 142.875 22 3.3 0.48 30
    JM719149 95 34 3 1.41 JM719113 150 27 2.5 0.76 35
    JHM720249 100 40 3 2.04 JHM720210 160 32 2.5 0.96 41
    LM720646 99.974 25.4 1.5 0.95 LM720610 146.05 19.05 1.5 0.39 25.4
    LM722949 114.3 27 3.3 1.13 LM722910 161.925 20.638 3.3 0.49 27.783
    L724349 120.65 25.4 3.3 1.1 L724310 166.688 19.05 3.3 0.45 25.4
    L730649 152.4 28.575 3.3 1.74 L730610 203.2 21.438 3.3 0.69 28.575
    JM734449 170 44.5 3 4.28 JM734410 240 37 2.5 2 46
    LL735449 177.8 20.638 1.5 1.04 LL735410 215.9 15.083 1.5 0.4 20.638
    JM736149 180 45 3 4.57 JM736110 250 37 2.5 2.1 47
    JM738249 190 44 3 4.67 JM738210 260 36.5 2.5 2.2 46
    LM739749 196.85 39.688 3.5 3.57 LM739710 257.175 30.162 3.3 1.74 39.688
    LM742745 212.725 46.038 3.5 5.69 LM742710 285.75 34.925 3.3 2.38 85.42
    LM742749 215.9 46.038 3.5 5.31
    HM803145 41.25 29.37 0.8 0.59 HM803110 88.9 23.02 3.3 0.31 30.162
    HM803146 41.275 29.37 3.5 0.58 HM803111 88.9 23.02 0.8 0.32 30.162
    HM803149 44.45 29.37 3.5 0.53 HM803112 92.075 23.02 3.3 0.39 30.162
    M802048 41.275 25.654 3.5 M802011 82.55 20.193 3.3 0.22 26.543
    HM803145 41.275 29.37 0.8 0.59 HM803110 88.9 23.02 3.3 0.31 30.162
    HM813146 41.275 29.37 3.5 0.58 HM813111 88.9 23.02 0.8 0.32 30.162
    HM813149 44.45 29.37 3.5 0.53 HM803112 92.075 23.02 3.3 0.39 30.162
    M804049 47.625 25.4 3.5 0.44 M804010 88.9 19.05 3.3 0.22 25.4
    HM804840 41.275 29.37 3.5 0.72 HM804810 95.25 23.02 3.3 0.35 30.163
    HM804849 48.412 29.37 3.5 0.6 HM804811 95.25 23.02 0.8 0.36 30.163
    LM806349C 53.975 20.244 2.5 0.32 LM806310 88.9 14.684 2 0.14 20.241
    LM806649 53.975 19.05 2.3 0.29 LM806610 88.9 13.492 2 0.13 19.05
    HM807040 44.45 36.512 3.5 1.14 HM807010 104.775 28.575 3.3 0.5 36.512
    HM807046 50.8 36.512 3.5 1.01 HM807011 104.775 28.575 0.8 0.5 36.512
    HM807049 53.975 36.512 3.5 0.94
    L812148 66.675 17.602 1.5 0.38 L812111 103.213 11.989 0.8 0.13 17.247
    JLM813049 70 25 1 0.59 JLM813010 110 20.5 2.5 0.3 26
    HM813840 55.562 36.512 3.5 1.7 HM813810 127 26.988 3.3 0.62 36.512
    HM813849 71.438 36.512 3.5 1.25
    HH814542 60.325 52.705 3.5 3.28 HH814510 152.4 41.275 3.3 1.74 53.975
    L814749 76.2 19.05 1.5 0.4 L814710 109.538 15.083 1.5 0.2 19.05
    LM814849 77.788 25.4 3.5 0.61 LM814810 117.475 19.05 3.3 0.29 25.4
    JL819349 95 20 5 0.58 JL819310 135 14 2.5 0.26 20
    JL820048 100 30 2.3 1.14 JL820012 150 26 2.3 0.67 32
    JM822049 110 35 3 1.63 JM822010 165 26.5 2.5 0.83 35
    JHM840449 200 62 3.5 10.39 JHM840410 300 51 2.5 5.15 65
    LM844049 223.838 46.038 3.5 5.57 LM844010 295.275 34.925 3.3 2.56 46.038
    LL889049 1270 65.088 6.4 LL889010 1435.1 47.625 6.4 40.68 69.85
    HM903249 44.45 28.575 3.5 0.63 HM903210 95.25 22.225 0.8 0.38 30.958
    M903345 41.275 23.812 3.5 0.55 M903310 92.075 16.67 1.5 0.24 26.195
    HM905843 44.988 31.75 2.5 0.89 HM905810 104.986 23.368 2.5 0.49 32.512
    HM907639 47.625 28.575 3.5 0.91 HM907614 111.125 20.638 3.3 0.5 30.163
    L910349 63.487 15.5 1 L910310 94.976 12 1 0.14 17
    HM911242 53.975 33.338 3.5 1.55 HM911210 130.175 23.812 3.3 0.67 36.513
    HM911245 60.325 33.338 5 1.39 JHM911211 130 22.649 3.3 0.65 36.512
    HM911249 61.912 33.338 3.5 1.36 HM911210 130.175 23.812 3.3 0.77 36.512
    JM913740 50 31 2.5 3.36 JM913715D 140 42 0.8 1.73 70
    H913842 61.912 39.688 3.5 2.23 H913810 146.05 25.4 3.3 0.88 41.275
    H913849 69.85 39.688 3.5 1.97 JH913811 150 25.4 3.3 1.07 41.275
    EL914049 76.2 9.525 1.3 0.14 EL914010 98.425 7.145 1.3 0.07 11.112
    HH914449 66.675 53.975 3.5 4.23 HH914412 117.8 37.308 3.3 2.51 57.15
    HM914545 69.85 33.338 4 1.67 HM914510 146.05 23.812 3.3 0.89 36.512
    H914841 68.262 46.038 3.5 2.89 H914811 152.4 35.1 3.3 1.53 47.626
    H916642 69.987 53.183 3.3 4.17 H916610 176.212 36.512 3.3 2.22 54.77
    H917849 82.55 53.183 3.3 4.06 H917810 180.975 35.72 3.3 2.16 53.975
    H919049 89.98 30.162 2 3.63 M919010D 161.9 44.45 1.5 1.8 69.85
    H919942 84.138 49 6.4 4.66 H919911 193.675 34.498 6.4 2.34 52
    LM921845 101.6 31.75 3.3 2.21 LM921810 177.8 19.05 3.3 0.86 34.925
    HH923649 101.6 73.025 6.4 11.13 HH923610 250.825 50.8 6.4 6.35 76.2
    H924045 111.125 52.388 3.5 5.63 H924010 214.312 39.688 3.3 2.79 55.562
    HH924349 111.125 71.438 6.4 19.84 HH924310D 241.3 107.95 1.5 11.1 158.75
    HH926749 120.65 82.55 6.4 15.04 HH926710 273.05 53.975 6.4 6.96 82.55
    HM926740 114.3 49.428 3.5 6.89 HM926710 228.6 38.1 3.3 2.78 53.975
    HM926749 127.792 49.428 3.5 5.9 HM911210 130.175 23.812 3.3 0.77 36.512



  • Previous:
  • Next:
    • Write your message here and send it to us

    Products categories

    • facebook
    • instagram
    • linkedin
    • twitter
    © Copyright - 2010-2023 : All Rights Reserved. Clutch Plate, Clutch Release Bearing, Truck Clutch Bearing,
